Double Penguin Refrigeration
Key Features:
Capable of handling extreme operating conditions and high-pressure ratios with specialized Economiser (ECO) operation, significantly increasing refrigeration capacity and system efficiency through liquid subcooling. Features flexible energy regulation options (e.g., 100/75/50% or 100/75/30% stepped control) to match varying thermal loads. Fully compatible with R22, R404A, and R507A refrigerants.
Ideal Applications: Large-scale industrial cold storage, quick-freezing tunnels, and heavy-duty commercial refrigeration systems.
Parameters:
| Model | Displacement (m³/h @ 50Hz) | Nominal Power (HP) | Max Operating Current (A) | Reference Net Weight (kg) |
|---|---|---|---|---|
| YLG20Z-84 | 84 | 20 | 45 | 183 |
| YLG30Z-100 | 100 | 30 | 68 | 189 |
| YLG40Z-140 | 140 | 40 | 79 | 201 |
| YLG50Z-165 | 165 | 50 | 124 | 219 |
| YLG60Z-192 | 192 | 60 | 144 | 238 |
| YLG75Z-250 | 250 | 75 | 162 | 323 |
